The VSM Workcell symbol denotes a U-shaped manufacturing cell. It is a way of organizing a flow between workstations and indicates multiple processes that are integrated into a manufacturing work cell. With a U-shaped manufacturing cell, the operator finishes their work in the same location they start in, eliminating the waste of walking from the end of the line back to the start. The value stream mapping Workcell is an arrangement of resources in a manufacturing environment to improve the quality, speed and cost of the process. Work cell manufacturing is where the resources – including labor, equipment, and raw materials – are consolidated in a single area for production.
The Lean Value Stream Mapping Workcell icon is part of a range of magnetic accessories to help you to create a working visual of your VSM initiative. You can purchase a complete VSM kit.
Each VSM Workcell icon is 2" x 2".
The Value Stream Mapping magnetic Workcell icon is printed on flexible thick vehicle grade quality 0.5mm magnetic sheets with a high quality PVC finish.
